A-101N Univer - Pilot / Micro Valve ISO 15218 15mm NC Ø1,2 2W DC

Ambient temperature: -5 ÷ +50 ° C
Operating medium: filtered compressed air 10 μm, with or without lubrication
Switching system: seating system
Max. Pressure: 9 bar
Fixing: by 2 screws M3
Connections: Interface to ISO 15128
Nominal diameter (mm): 1.2 | 1.5
Nominal flow rate (Nl / min): 26 | 38
Max. Frequency: 2700 operations / min
Valve body: technopolymer (external coating of aluminum)
Seals: NBR
Power consumption: 2W DC / 2VA AC (Ø 1.2) -2.5W DC / 3.5VA AC (Ø 1.5)
Electrical connection: Plug 15mm - Molex plug 2-pin or cast-on strands
Voltage: 24V DC - 12V DC - 24V AC - 110V AC - 230V AC
Manual operation: sunk push button 1 position
Degree of protection (with connector): IP65
